Product Description:
With Audio outputs, this Digital Signage System is perfect for
those looking to display video content with accompanying sound. The
178° Viewing Angle ensures that content is visible from almost any
angle, making it perfect for high-traffic areas such as malls or
airports.
The A40 CPU ensures that this Wall-Attached Digital Display is
powerful enough to handle all of your digital signage needs. And
with the option to choose between Android or Windows operating
systems, this Digital Signage System is versatile and customizable
to fit your specific needs.
Whether you're looking to display advertisements, menus, or other
important information, our Wall-Installed Digital Signage System is
the perfect solution. Don't settle for outdated and clunky displays
- upgrade to our sleek and modern Wall-Attached Digital Display
today.
Technical Parameters:
| Device parameters |
| Single screen display area | 32-inch display area: 702*397mm 43-inch display area: 943*532mm 49-inch display area: 1074*604mm 55-inch display area: 1213*684mm 65-inch display area: 1428*803mm 75-inch display area: 1649*930mm 86-inch display area: 1899*1066mm |
| Screen resolution | 2k 1920*1080；4k 3840*2160 |
| Dot pitch | 0.53025 (H) × 0.53025 (V) mm |
| Horizontal frequency | 60KHZ－73KHZ |
| Vertical frequency | 47HZ/ 63HZ |
| Perspective | 178° |
| Colour | 16.77 bit true color |
| Lamp life | 50000 hours |
| Average brightness | 350cd/m2 |
| Contrast | 1000:01:00 |
| Storage temperature | -20 ℃～ 60 ℃ |
| Operating temperature | 0 ℃～ 40 ℃ |
| Response time | 5-10(Tr/Tf)ms |
| Installation | Wall Mounted (with wall mount bracket) |
| Android solution |
| Support system | Android 7.0 |
| CPU | RK3188/RK3288/RK3568/RK3399 |
| Internal storage | 8G/16G/32G |
| RAM | 1G/2G/4G |
| Memory expansion | support |
| Network support | RJ45 network port, WiFi, wireless 4G (optional) |
| Bluetooth | Support bluetooth 4.0 |
| HDMI | Support HDMI output |
| Commercials play | Supports stand-alone mode (USB stick) / LAN / WAN. Supports loop,
timer, interpolation, split screen partitioning, subtitle playback
and any combination of multimedia material. Remote background
control. (Optional) |
| USB | USB2.0*1 USB3.0*1 |
| X86 computer solution |
|
| Support system | windows7/windows10 |
| Industrial Control Motherboard | i3 (I5/I7 optional) |
| Processor | Dual core frequency 1.8GHZ |
| RAM | 8G storage memory(16G/32G optional) |
| Storage card | 128G solid state drive(256G/512G optional) |
| WIFI, 3G (optional) | Built-in MIMI150M wireless network card |
| USB interface | USB3.0*2USB2.0*2 |
| Signal interface | 1*VGA,1*HDMI ,1*DVI,audio interface etc |
| Sound | Built-in 2x8 ohm 5W woofer |
| Touch system |
| Input method | Activate with fingers |
| Induction method | Infrared/Capacitance |
| Positioning accuracy | Classic accuracy is less than 2mm |
| Cursor speed | 180 points/sec |
| Resolution | 4096*4096 |
| Response time | First point (click): 25ms; continuous (writing): 8ms |
Applications:
- Retail stores
- Hospitals and healthcare facilities
- Hotels and resorts
- Corporate offices
- Schools and universities
The HN-3201BG is a high-quality, wall-mounted digital display that
provides a clear and vibrant image. It is perfect for displaying
advertising, news, weather updates, and other content. The
wall-mounted design is ideal for saving space and can be installed
in any location, making it perfect for small shops and large
corporations alike.
This Wall-Mounted Digital Display is manufactured in Guangdong,
CHINA, and is certified by 3C, FCC, CE, and ROHS. The minimum order
quantity is only 1 PC, and the price is negotiable. The packaging
includes EPE and foam, and the carton is placed in a wooden case
for added protection during shipping. Delivery time is typically
5-10 work days upon payment, and payment terms include L/C, T/T,
Western Union, and MoneyGram. The HN-3201BG has a supply ability of
2000 Pieces Per Month.
The HN-3201BG is equipped with USB2.0 and 1GB RAM, making it easy
to upload and display content. It operates within a temperature
range of -20°C to 50°C and features a time switcher, allowing you
to schedule content to display at specific times. The display type
is LCD Digital Signage, providing a clear and vibrant image that is
easy to read.
Overall, the HONGNUO HN-3201BG Wall-Mounted Digital Display is a
versatile and reliable solution for any business or organization
looking to display digital content. Whether you are looking for a
Wall-Mounted Digital Display for your retail store, hospital,
hotel, corporate office, or school, the HN-3201BG is the perfect
solution.
Customization:
Our wall-mounted digital signage system is certified by 3C, FCC,
CE, and ROHS, ensuring quality and safety for all users. With a
negotiable price and a minimum order quantity of 1 PC, you can get
started on showcasing your content in no time.
Each unit is packed in a carton with EPE and foam, and then placed
in a wooden case for secure transportation. Delivery time is 5-10
work days upon payment, and we accept payment through L/C, T/T,
Western Union, and MoneyGram. With a supply ability of 2000 pieces
per month, we're ready to meet your customization needs for our
wall-mounted digital signage system.
Support and Services:
The Wall Mounted Digital Signage product offers comprehensive
technical support and services to ensure optimal performance and
customer satisfaction. Our team of experts is available to assist
with any issues or questions related to the installation,
configuration, and operation of the product.
We provide regular software updates to enhance functionality and
address any potential security vulnerabilities. Our services also
include remote monitoring and diagnostics to quickly identify and
resolve any technical issues that may arise.
In addition, we offer training and resources to help users fully
utilize the features and capabilities of the Wall Mounted Digital
Signage product. Our goal is to provide reliable and efficient
support to minimize downtime and ensure a seamless user experience.
Packing and Shipping:
The wall mounted digital signage product will be carefully packaged
to ensure its safe delivery. It will be placed in a sturdy
cardboard box with appropriate padding to prevent any damage during
transit.
Shipping:
We offer free shipping for all orders within the United States. The
product will be shipped via a reliable courier service and will
typically arrive within 3-5 business days. International shipping
is also available for an additional fee, and delivery times may
vary depending on the destination.
